Superwinch S100430 - Industrial SI 12000 Hydraulic Winch

Name: Superwinch S100430 - Industrial SI 12000 Hydraulic Winch
Brand: Superwinch
SKU: SWINCH-S100430
Availability: OutOfStock

Superwinch S100430 - Industrial SI 12000 Hydraulic Winch

Superwinch | S100430
SKU: SWINCH-S100430

$0.00 USD

~~$0.00 USD~~ $0.00 USD

Sale Sold out

Shipping calculated at checkout.

Out of stock

Superwinch S100430 - Industrial SI 12000 Hydraulic Winch

SI 12000 Hydraulic Winch

Hydraulic Winch; 12000 lbs.; Standard Drum; Manual Free-Spool; 2-Stage Planetary; 16:1 Gear Ratio; Spring Applied Hydraulic Release Multi Disc Brake; Roller Fairlead;

Superwinch designs and delivers automotive products that give you the function you need to fit your active lifestyle. Superwinch products are proudly designed, tested and engineered in San Dimas, California, USA. Innovation, passion and consistency have made Superwinch one of the industry's leading manufacturers. Our diverse range of products is backed by a superior manufacturer warranty. When it comes to your vehicle, Superwinch is the name you can trust.

12000 lb. standard drum hydraulic winch
16:1 gear ratio
Roller fairlead

Brake System: Spring-Applied, Hydraulic Release Multi-Disc

Maximum Input Flow: 15 gpm/57 lpm

Winch Model: SI 12000

Standards Compliance: SAE J706 / EN 14492-1. CE Directives--Machinery 2006/42/EC; Noise Emission 2000/14/EC; Electromagnetic Compatibility 2014/30/EC

Rope Attachment: Quad-drilled (Left-hand or Right-hand winding drum) Provides flexibility to mount winch in the best orientation

Recommended Rope: 3/8" (SAE J706) 11 mm (EN 14492-1)

Motor Type: 120 cc Hydraulic Gear Motor

Minimum Rope Breaking Strength: 15100 lbs. (SAE J706); 106.8 kN (EN 14492-1)

Maximum Input Pressure: 2300 psi/158 bar

Material: Steel

Can Ship By Ground Delivery: No

Lubrication: Synthetic Grease

Load Block: Superblock Bi-Directional Load Control Valves

Gear System: 2-stage planetary

Gear Ratio: 16:1

Finish: Powder Coated
