Spicer 916366-1 - Short Couple Drive Shaft
Spicer 916366-1 - Short Couple Drive Shaft
SKU: FSGR-916366-1
Regular price
$1,205.99 USD
Regular price
$1,621.66 USD
Sale price
$1,205.99 USD
Shipping calculated at checkout.
Out of stock
Quantity
DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.
Couldn't load pickup availability
Spicer 916366-1 - Short Couple Drive Shaft
Short Couple Drive Shaft
Demand Genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.
- Dana manufactured Spicer Driveshafts are designed, engineered, tested, and manufactured to meet or exceed OE requirements.
- Dana manufactured Spicer driveshafts are designed to be drop-in replacements, eliminating assembly time.
- Meets or exceeds the performance requirements of the original factory driveshaft
Series: 1350
Phased - Degrees: 0
Unwelded/Welded Assembly: Welded
Shaft Material: Steel
Max Slip (IN): 0.7480
Max Slip (MM): 19.0000
Notes: Flange Yoke at Both Ends
CL Yoke To CL Yoke (IN) - COLL: 7.0709
CL Yoke To CL Yoke (MM) - COLL: 179.6000
Mid Slip (MM): 9.5000
Mid Slip (IN): 0.3740
FF(Flange Face) To FF (MM)-COLL: 258.8000
Phase (Yes/No): No
End 1 Type SJ Side: 3-2-119
CV Joints Included: No
End 2 TJ Side: 3-2-119
CL Yoke To Flange Face(IN)-COLL: 8.6299
Slip Assembly: No
FF(Flange Face) To FF (IN)-COLL: 10.1890
CL Yoke To Flange Face (MM)-COLL: 219.2000
CL Yoke To Flange Face (MM)-INST: 228.700
FF(Flange Face) To FF (IN)-INST: 10.5630
FF(Flange Face) To FF (MM)-INST: 268.3000
1/2 Max Slip (IN): 0.3740
1/2 Max Slip (MM): 9.5
