Spicer 6.5-1-1801 - Automatic Transmission Mission; Output Shaft; Companion Flange
Spicer 6.5-1-1801 - Automatic Transmission Mission; Output Shaft; Companion Flange
SKU: FSGR-6.5-1-1801
Regular price
$480.99 USD
Regular price
$646.66 USD
Sale price
$480.99 USD
Shipping calculated at checkout.
Out of stock
Quantity
DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.
Couldn't load pickup availability
Spicer 6.5-1-1801 - Automatic Transmission Mission; Output Shaft; Companion Flange
Automatic Transmission Mission; Output Shaft; Companion Flange
Demand Genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.
- Genuine OE quality. Tested and proven.
- Built to meet OE standards set by Dana
- Tested and validated to rigorous OE specifications
- Latest production upgrades ensure genuine Spicer parts are as good or better than the OE parts they replace
Series: 1810
Material: Steel
Spline Count: 18 I
Involute Spline: Y
Companion Flange Assembly: N
Flange Face To End Of Hub (G): 4.031
Ground Hub Diameter In.: 3.500
Length Thru Hole (F) In.: 3.375
Major Diameter (D) In.: 2.364
Pilot Diameter (C) In.: 7.750 - FEMALE
Bolt Circle Dia.(B) In.(FL YK): 7.250
Bolt Hole Diameter In (FL YK): 0.438 - DRILLED
Number Of Holes (FL YK): 12
