Spicer 4-1-4501X - Automatic Transmission; Output Shaft Flange
Spicer 4-1-4501X - Automatic Transmission; Output Shaft Flange
SKU: FSGR-4-1-4501X
Regular price
$0.00 USD
Regular price
$0.00 USD
Sale price
$0.00 USD
Shipping calculated at checkout.
Out of stock
Quantity
Couldn't load pickup availability
Spicer 4-1-4501X - Automatic Transmission; Output Shaft Flange
Automatic Transmission; Output Shaft Flange
Demand genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non genuine parts simply cannot deliver.
- Genuine OE quality. Tested and proven.
- Built to meet OE standards set by Dana
- Tested and validated to rigorous OE specifications
- Latest production upgrades ensure genuine Spicer parts are as good or better than the OE parts they replace
Series: 1480
Material: Steel
Spline Count: 34 I
Involute Spline: Y
Companion Flange Assembly: Y
Flange Face To End Of Hub (G): 3.344
Ground Hub Diameter In.: 2.562
Length Thru Hole (F) In.: 2.750
Major Diameter (D) In.: 1.790
Pilot Diameter (C) In.: 3.750 - FEMALE
Bolt Hole Diameter In (FL YK): 0.500 - DRILLED
Number Of Holes (FL YK): 4
