Spicer 3-53-1031 - DRIVE SHAFT MIDSHIP STUB SHAFT
Spicer 3-53-1031 - DRIVE SHAFT MIDSHIP STUB SHAFT
SKU: FSGR-3-53-1031
Regular price
$107.99 USD
Regular price
$144.96 USD
Sale price
$107.99 USD
Shipping calculated at checkout.
Out of stock
Quantity
DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.
Couldn't load pickup availability
Spicer 3-53-1031 - DRIVE SHAFT MIDSHIP STUB SHAFT
DRIVE SHAFT MIDSHIP STUB SHAFT
Demand genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non genuine parts simply cannot deliver.
- Dana manufactured Spicer components are designed, engineered, tested, and manufactured to meet or exceed OE requirements.
- Spicer components are engineered to meet or exceeds the performance requirements of the original factory driveline component
- Tested for unparalleled reliability
- Strength and durability for long life
- Dana engineering-approved for fit, form and function
Series: 1310-1410
Material: Steel
Style: 1
Fits Tube Diameter: 3
Involute: N
Fits Tube Wall: 0.083
Butt Diameter: 2.845
Bearing Diameter (C) In.: 1.575
Bearing Diameter (Max): 1.5752
Spline End To Weld (K) In.: 7.062
Spline Length (L) In.: 4.438
Spline O.D.: 1.5000
Bearing Diameter (Min): 1.5747
For Use With: Outboard Slip Yoke
Shoulder Diameter (B) In.: 1.810
Shoulder Length (G) In.: 0.875
Spline End To Brg Shoulder (Y): 5.940
Bearing Diameter Length: 1.5
