Spicer 250-53-11 - DRIVE SHAFT MIDSHIP STUB SHAFT
Spicer 250-53-11 - DRIVE SHAFT MIDSHIP STUB SHAFT
SKU: FSGR-250-53-11
Regular price
$0.00 USD
Regular price
$0.00 USD
Sale price
$0.00 USD
Shipping calculated at checkout.
Out of stock
Quantity
Couldn't load pickup availability
Spicer 250-53-11 - DRIVE SHAFT MIDSHIP STUB SHAFT
DRIVE SHAFT MIDSHIP STUB SHAFT
Demand genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.
- Dana manufactured Spicer components are designed, engineered, tested, and manufactured to meet or exceed OE requirements.
- Spicer components are engineered to meet or exceeds the performance requirements of the original factory driveline component
- Tested for unparalleled reliability
- Strength and durability for long life
- Dana engineering-approved for fit, form and function
Series: SPL250
Material: Steel
Thread Size: M30X2-6G
Style: 2
Fits Tube Diameter: 5.197
Involute: Y
Fits Tube Wall: .157
Butt Diameter: 4.746
Bearing Diameter (C) In.: 2.362
Bearing Diameter (Max): 2.3622
Spline End To Weld (K) In.: 5.291
Spline Length (L) In.: 2.618
Spline O.D.: 2.350
Bearing Diameter (Min): 2.3617
For Use With: End Yoke Or Companion Flange
Shoulder Diameter (B) In.: 2.886
Shoulder Length (G) In.: .812
Spline End To Brg Shoulder (Y): 3.980
