Spicer 250-4-61-1X - PINION SHAFT END YOKE

Spicer 250-4-61-1X - PINION SHAFT END YOKE

Spicer | 250-4-61-1X
SKU: FSGR-250-4-61-1X
$390.99 USD
$525.15 USD $390.99 USD
Sale Sold out
Shipping calculated at checkout.

Out of stock

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

Spicer 250-4-61-1X - PINION SHAFT END YOKE

PINION SHAFT END YOKE

Demand genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.

  • Genuine OE quality. Tested and proven.
  • Built to meet OE standards set by Dana
  • Tested and validated to rigorous OE specifications
  • Latest production upgrades ensure genuine Spicer parts are as good or better than the OE parts they replace
  • Dana engineering-approved for fit, form and function
Assembly: Y
Hub Diameter R: 2.938
Includes Slinger/Plug: Y
Involute Spline: Y
Length Thru Hole Q: 2.500
Outside Yoke Dimension (In) E: 6.417
Yoke Bearing Dimension (In) D: 2.362
Yoke Style: HR
Type: Splined Hole
Spline Count: 44
Material: Steel
Series: SPL250
Major Diameter: 2.274
C/L To End Hub S: 5.484
