Spicer 250-4-101-1X - PINION SHAFT END YOKE
Spicer 250-4-101-1X - PINION SHAFT END YOKE
SKU: FSGR-250-4-101-1X
Regular price
$303.99 USD
Regular price
$408.74 USD
Sale price
$303.99 USD
Shipping calculated at checkout.
Out of stock
Quantity
DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.
Couldn't load pickup availability
Spicer 250-4-101-1X - PINION SHAFT END YOKE
PINION SHAFT END YOKE
Demand genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.
- Genuine OE quality. Tested and proven.
- Built to meet OE standards set by Dana
- Tested and validated to rigorous OE specifications
- Latest production upgrades ensure genuine Spicer parts are as good or better than the OE parts they replace
Series: SPL250
Material: Steel
Spline Count: 46
Type: Splined Hole
Assembly: Y
Hub Diameter R: 3.375
Includes Slinger/Plug: Y
Involute Spline: Y
Length Thru Hole Q: 3.195
Outside Yoke Dimension (In) E: 6.417
Yoke Bearing Dimension (In) D: 2.362
Yoke Style: HR
Major Diameter: 2.390
C/L To End Hub S: 6.760
C-Bore Depth: 0.580
