S&S Cycle 320-0469 - 00-06 BT 4-5/8in Stroke Flywheel Assembly w/o Sprocket Shaft Bearing Race
S&S Cycle 320-0469 - 00-06 BT 4-5/8in Stroke Flywheel Assembly w/o Sprocket Shaft Bearing Race
SKU: SSC-320-0469
Low stock: 1 left
DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.
Couldn't load pickup availability
S&S Cycle 320-0469 - 00-06 BT 4-5/8in Stroke Flywheel Assembly w/o Sprocket Shaft Bearing Race
88B, S&S® 124
This 4-5/8" stroke 8-1/2" diameter flywheel assembly fits 2000-'06 internally balanced HD® big twin models as part of an S&S® 124" Hot Set Up Kit®. Sprocket shaft does not have a stock style bearing race pressed on. This flywheel assembly is for crankcases with Timken® sprocket shaft bearing. Flywheel assembly is three piece design. Pinion and sprocket shafts are forged as part of the flywheel. Assembly is trued to less than .0005" runout on pinion and sprocket shaft bearing surfaces, making them capable of higher rpm and fully compatible with gear drive cams.
