Pertronix - 30771
Coil Flame-Thorower Ford V6 Ecoboost 3.5L:3-Pin Brown;Single Coil 2011-20
Pertronix Flame-Thrower Coil Ford V6 Ecoboost 3.5L;3-Pin Brown Connector; 2011-20; Single Coil; Optimized Coil Design For 15 Percent More Spark Energy; Direct OEM Replacement Ford: BLZ3Z-12029-C, Motorcraft Dg-549
Flame Thrower Coils feature an optimized coil design which increases the spark energy by 15% over OEM coils.
- 30,000 Volts. Direct OEM replacement.
- Optimized coil design yields at least 15% more energy available for the spark than the most common OEM coils.
- Provides the spark energy throughout the RPM range and with no energy degradation up to 11,000 engine RPMs. Plated Copper terminals for added current conduction.
- Moisture resistant construction ensures long life in harsh environments. High-temp boot sustains seal and form. Epoxy molded for shock and vibration resistance.
- Limited 90 Day Warranty
Ballast Resistor Included: No
Coil Internal Construction: Epoxy
Coil Shape: Same as Factory
Coil Type: Coil Pack
Coil Type: No
Coil Wire Attachment: Coil-on-Plug
Coil Wire Included: No
Color: Black
EmissionFullDES: 4 - This Product is considered a Replacement Part per CARB and EPA regulations for emissions compliance and is legal for sale and use on specified vehicles in all 50 states as stated in Manufacturer’s Application Guide and Installation Instructions.
Finish: Matte
Grade Type: Stock Replacement
Ignition Type: Computer Controlled
Maximum Voltage: 30000
Mount Type: Factory
Mounting Bracket Included: Integrated
Mounting Hardware Included: No
Mounting Position: Factory
Primary Inductance: 2.2
Primary Resistance: 0.5
Requires External Resistor: No
Secondary Resistance: 9000
Turns Ratio: 85:1
Voltage: 12
