Mishimoto MMRAD-RGR-19 - 2019+ Ford Ranger 2.3L Aluminum Performance Radiator

Mishimoto MMRAD-RGR-19 - 2019+ Ford Ranger 2.3L Aluminum Performance Radiator

Mishimoto | MMRAD-RGR-19
SKU: MMRAD-RGR-19
$699.95 USD
$770.00 USD $699.95 USD
Sale Sold out
Shipping calculated at checkout.

17 in stock

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

Mishimoto MMRAD-RGR-19 - 2019+ Ford Ranger 2.3L Aluminum Performance Radiator

Performance Aluminum Radiator, fits Ford Ranger 2.3L 2019 - 2023

Aluminum radiator engineered for efficient heat dissipation and optimal engine cooling. Precision-fit design ensures easy installation, corrosion resistance, and reliable performance across varied driving conditions.

The 2019 - 2023 Ford Ranger 2.3L EcoBoost is one of the most capable small trucks on the planet, and it deserves a cooling system that's equally capable. This Mishimoto Performance Aluminium Radiator is constructed from high-quality aluminium with precision TIG-welded end tanks for increased durability and resistance to heat and pressure. The direct-fit design means this radiator fits without any trimming or modifications. To make sure our radiator performs as well as it fits, we've also increased its core volume by 78 percent and its fluid capacity by 51.3 percent. Core thickness is increased by 43.7 percent, and external fin surface area is increased by 95 percent to make the most of the air coming through the grille. This Mishimoto 2019 - 2023 Ford Ranger 2.3L EcoBoost Performance Aluminium Radiator includes a magnetic drain plug to keep your coolant free of metallic debris and is backed by our Mishimoto Lifetime Warranty to keep your Ranger cool as long as you own it.

  • Increases core volume by 78-percent over stock radiator
  • Increases fluid capacity by 51.3-percent over stock radiator
  • 43.7-percent thicker core than stock radiator
SellingPoint14: N/A
SellingPoint15: N/A
Install Difficulty: 2
Core Finish: Uncoated
Core Height: 26.18
Core Length: 23.22
Core Material: Aluminum
Core Row Quantity: 2
Core Thickness: 1.89
Down Flow Or Cross Flow Type: Cross Flow
Drain Plug Included: Yes
Drain Plug Thread Size: M12 - 1.5
Fluid Capacity: 3.39
Inlet Diameter: 0
Inlet Location: Top Right
Outlet Diameter: 0
Outlet Location: Bottom Left
Overall Height: 0
Overall Length: 0
Overall Width: 0
Radiator Cap Included: No
Transmission Oil Cooler Fitting Type: N/A
Transmission Oil Cooler Included: No
TechSpec Overall Height (in): N/A
TechSpec Overall Length (in): N/A
TechSpec Overall Width (in): N/A
TechSpec Core Length (in): 23.22
TechSpec Core Height (in): 26.18
TechSpec Fluid Capacity (gal): 3.39
TechSpec Rows: 2
TechSpec Inlet (in): N/A
TechSpec Outlet (in): N/A
TechSpec Core Thickness (in): 1.89
TechSpec Drain Plug Thread Size: M12 x 1.5
TechSpec DPI: N/A
TechSpec Material: Aluminum
TechSpec Applications: 2019 - 2023 Ford Ranger 2.3L EcoBoost
TechSpec Engine Codes: N/A
TechSpec Chassis Codes: T6
TechSpec Note: This radiator reuses the factory mounting grommets. If your grommets are damaged, you may purchase replacements under Ford part #EB3Z-6C681-B
TechSpec Includes: Mishimoto Performance Aluminum Radiator-- Mishimoto Magnetic Drain Plug--Mounting Hardware--Mishimoto Lifetime Warranty
SellingPoint01: Direct fit for 2019 - 2023 Ford Ranger 2.3L EcoBoost
SellingPoint02: Increases core volume by 78-percent over stock radiator
SellingPoint03: Increases fluid capacity by 51.3-percent over stock radiator
SellingPoint04: 43.7-percent thicker core than stock radiator
SellingPoint05: 95-percent increase in fin surface area
SellingPoint06: Full aluminum construction with durable, TIG-welded end tanks
SellingPoint07: Includes Magnetic Drain Plug to capture any metallic debris/fragments in your cooling system
SellingPoint08: Mishimoto Lifetime Warranty
SellingPoint09: N/A
SellingPoint10: N/A
SellingPoint11: N/A
SellingPoint12: N/A
SellingPoint13: N/A
