Melling M452HV - High Volume Replacement Oil Pump

Melling M452HV - High Volume Replacement Oil Pump

Melling | M452HV
SKU: BCBCM452HV
$165.99 USD
$182.59 USD $165.99 USD
Sale Sold out
Shipping calculated at checkout.

3 in stock

Melling M452HV - High Volume Replacement Oil Pump

Oil Pump - Wet Sump - Internal - High Volume - Mopar Gen III Hemi - Each

Stock Replacement : High Volume; Standard Pressure; Aluminum Oil Pump With Seal

Made in USA. Melling high volume oil pumps increase the amount of oil flow by an average of 12% through the engine improving oil pressure at idle providing dependable performance every time in every application. Every Melling high volume oil pump is engineered and assembled to the highest production standards from high quality materials. All Melling high volume oil pumps use the latest in gear and gerotor technology to provide the highest level of quality and performance. High volume gears are machined to close tolerances to ensure proper engine pressure and correct, efficient pump operation. End plates are precision ground for maximum wear resistance. Every Melling oil pump is individually tested for pressure and flow under conditions designed to duplicate actual engine operating conditions.

Pickup Screen Included: No
Intermediate Shaft Included: Not Applicable
Inlet Size (in): 0.950
Inlet Size (mm): 24.00
Cover Material: Cast Iron
Bolts Included: No
Bushing Included: No
Cotter Pin Included: No
Governor Spinner Included: No
Guide Included: Not Applicable
Nylon Bushing Included: No
O-Ring Included: Yes
Pump Cover Included: Yes
Shaft Material: Not Applicable
Timing Cover Included: No
Washers Included: No
Spacer Included: No
Gears Included: Not Applicable
Finish: Rust Preventative
Width: 7.500
Width: 190.00
Height: 5.400
Height: 137.00
Gasket Or Seal Included: Yes
Mounting Hole Quantity: 4
Housing Material: Aluminum
Drive Type: Crankshaft
Rotor Material: Steel
Oil Pump Type: Rotary
Pickup Tube Diameter: 0.950
Pickup Tube Diameter: 24.00
Solenoid Included: No
Mounting Hole Diameter: 0.375
Mounting Hole Diameter: 10.00
Adjustable Bypass Pressure: No
Additional Cover Shaft Support: No
Alternate Pressure Springs Included: No
Adjustable Pickup Screen: Yes
Oil Pump Pressure Type: Standard Pressure
Oil Pump Volume Type: High Volume
Additional Volume Over Stock Percentage: 12
Grade Type: Improved Design
