Mcleod 563408HSK - Aluminum Flywheel Heat Shield Kit w/ Hardware (For 563408/563406/563100)

Mcleod 563408HSK - Aluminum Flywheel Heat Shield Kit w/ Hardware (For 563408/563406/563100)

Mcleod | 563408HSK
SKU: MC-563408HSK
$62.99 USD
$69.29 USD $62.99 USD
Sale Sold out
Shipping calculated at checkout.

71 in stock

Mcleod 563408HSK - Aluminum Flywheel Heat Shield Kit w/ Hardware (For 563408/563406/563100)

Heat Shield Kit For 563408/563406/563100 Aluminum Flywheel. Includes Screw-In Heat Shield And Hardware

McLeod Racing Replacement Flywheel Friction Plates are constructed of incredibly strong A36 high carbon steel to deliver superior longevity and disc engagement. Each friction plate is heat-treated and meets high specifications for performance output. With McLeod Racing replacement flywheel heat shields, there is no need to resurface or replace the entire flywheel when changing or replacing the clutch, saving both time and money.

  • The McLeod Racing removable heat shield allows users to replace the steel drive surface in the flywheel for a new drive surface when installing a new clutch system.
Flywheel Insert Material: A36 Steel
Flywheel Insert Outside Diameter (in.): 11.000
Flywheel Insert Inside Diameter (in.): 6.125
Mounting Hole Pattern: 20 Hole
Flywheel Insert Thickness (in.): 0.140
Notes: For use with 563406, 563408, 563100 McLeod Racing flywheels. This kit will NOT transfer or convert a flywheel that was originally equipped with a riveted in heat-shield.
Hardware Included: Yes
Quantity: Sold individually.
