Mcleod 360821 - Pressure Plate 12in Diaphragm Ford 11.5inLong Pattern

Mcleod 360821 - Pressure Plate 12in Diaphragm Ford 11.5inLong Pattern

Mcleod | 360821
SKU: MC-360821
Regular price $241.99 USD
Regular price $245.00 USD Sale price $241.99 USD
Sale Sold out
Shipping calculated at checkout.

127 in stock

Quantity

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

Mcleod 360821 - Pressure Plate 12in Diaphragm Ford 11.5inLong Pattern

Clutch Pressure Plate - Diaphragm - 12.00 in Diameter - 2250 lb Static Pressure - 3-9/16 in Bolt Circle - Ford - Each

Pressure Plate:Diaphragm: 12" Ford Long Pattern: #2250 :Ford : Each

McLeod Racing makes quality performance pressure plates for a wide variety of vehicles--domestic, imported, new, classic, you name it. We manufacture diaphragm, Borg & Beck, and Long types, with both aluminum and ductile-iron pressure rings. Not only that, we have applications designed for drag racing, road racing, oval tracks, and even the fabled dry lakes and salt flats of California, Nevada, and Utah. Chances are, we have what you need!

  • • Drag Racing, Road Racing, Oval Tracks • Diaphragm, Borg & Beck, and Long types. • General Motors, Ford, Chrysler and Import applications.
Make: Ford
Application: Ford Big Block 429-460; 332-428 BB Fe
Pressure Plate Diameter (in.): 12.000
Pressure Plate Pattern: Ford Long Pattern
Bolt Circle: 3-9/16
Clamp Load: 2250 Lbs
Counterweight Assist: No
Bolt Holes Dia: 5/16 x 18
Dowel Pins Required: No
Hardware Included: No
SFI Approved: Yes
