Mcleod - 139077
Piston:Hydraulic Bearing:Adjustable:1300 Series: Short Stack Height:Each
McLeod Racing adjustable height pistons help maintain proper mechanical linkage geometry. Each of their offered selections presents three variable height locations--and they utilize angular contact, constant-running bearings for long life and durability. McLeod adjustable height pistons are exclusive piston replacements for their bolt-on style bearing.
Height 2 Spacers: 2.740In.
Height 3 Spacers: 2.890
Bearing Face O.D. (in.): 3.000
Bearing Face I.D. (in.): 1.590
Bearing Thickness: 0.500In.
Height 0 Spacers: 2.440In.
Height 1 Spacers: 2.590In.
