Holley EFI - 522-361S
Holley Terminator X Fuel Injector - Individual
Sniper Fuel Injector; Bosch/EV1 Style Injectors; 36 lbs./hr.; 1 Each;
Sniper EFI Fuel Injectors feature a precision lapped disc valve, high-quality brass windings, and high-temp O-rings. These injectors provide excellent linearity with no discernible "bounce" at low pulse widths as commonly found in other injectors.
- PICO/EV6 style performance injector
- High impedance (12.2 Ohms) for use with saturated drivers
- Rated injector flow: 36 lb/hr @ 43 PSI
- Supports up to 575 horsepower (set of 8)
- Tri-cone spray pattern
Body Diameter: 0.65
Body Length: 1.85"
Body Style: EV6
Brand: Holley EFI
Category: Air and Fuel Delivery
Connector Series: EV6
Emission Code: 4
Flow Rate: 36
Fuel Type: E-85, Gasoline
Gasket Or Seal Included: Yes
Grade Type: Performance
Impedance: High (12.2 Ohm)
O-Ring to O-Ring: 1.421
part type: Fuel Injector
Product Type: Fuel Injector
Rated Injector Flow: 36 lb/hr
Sub Category: Fuel Injection System and Related Components
Terminal Gender: Male
Terminal Quantity: 1
Terminal Type: Blade
Warning: California Proposition 65
Wiring Harness Included: No
