Fuelab 30302 - Velocity Series Lift Pump 100GPH 8psi Duramax

Fuelab 30302 - Velocity Series Lift Pump 100GPH 8psi Duramax

Lift Pump for 2001-2016 GM Duramax 100GPH - Pre-Set Internal Bypass at 8psi

System Feaures

• Diesel fuel compatible
• Up to 500HP Support
• Internal bypass at 8psi
• High efficiency sling vane positive displacement pump
• Special housing shape for extremely quiet operation and steady pressure
• Carbon 9-vane construction with pressure balanced rotor for high reliability
• Replaceable or cleanable filter element
• Backed by a limited lifetime warranty

Motor Features:

• Lightweight super-efficient DC brushless motor reduces current draw
• Low mass rotor for high speed reaction to changes in speed and flow
• Powerful high flux density Neodymium rare earth magnets
• No motor brushes to wear out or corrode (low-Sulfur diesel, no problem)
• Wet motor design, no dynamic shaft seals that can wear out

Electronic Features:

• 12 to 24 volt vehicle electrical system compatibility
• Continuous duty-motor

Construction Features:

• Compact, lightweight design
• Billet Aluminum Construction with anodize per MIL-A-8625, Type II
• High quality mounting brackets that mount directly to frame - no drilling
• Long-life, multi-fuel compatible Fluorosilicone static seals
• Accepts standard or port style -10AN fittings
• Standard canister style filter with water separation feature
• Install kits sold separately
