Fuelab 10301 - Velocity Series 100GPH Lift Pump 18psi Internal Bypass 1998.5-2013 Dodge Cummins

Fuelab 10301 - Velocity Series 100GPH Lift Pump 18psi Internal Bypass 1998.5-2013 Dodge Cummins

100GPH Lift Pump for 1998.5-2013 Dodge Cummins (Pump Only). Internal Bypass Pre-Set at 18psi

Lift Pump Features

• Diesel fuel compatible
• Internal bypass at 18psi
• High efficiency sling vane positive displacement pump
• Special housing shape for extremely quiet operation and steady pressure
• Carbon 9-vane construction with pressure balanced rotor for high reliability
• Replaceable or cleanable filter element
• Backed by a limited lifetime warranty

Motor Features:

• Lightweight super-efficient DC brushless motor reduces current draw
• Low mass rotor for high speed reaction to changes in speed and flow
• Powerful high flux density Neodymium rare earth magnets
• No motor brushes to wear out or corrode (low-Sulfur diesel, no problem)
• Wet motor design, no dynamic shaft seals that can wear out

Electronic Features

• 12 to 24 volt vehicle electrical system compatibility
• Continuous duty-motor

Construction Features

• Compact, lightweight design
• Billet Aluminum Construction with anodize per MIL-A-8625, Type II
• High quality mounting brackets
• Long-life, multi-fuel compatible Fluorosilicone static seals
• Accepts standard or port style -10AN fittings
• Install kits sold separately
