Fox 981-20-400-R - CLASS 1/2-1600 FRONT FACTORY RACE 2.0 X 10 EXTERNAL BYPASS (4 TUBE) REMOTE SHOCK (RIGHT)

Fox 981-20-400-R - CLASS 1/2-1600 FRONT FACTORY RACE 2.0 X 10 EXTERNAL BYPASS (4 TUBE) REMOTE SHOCK (RIGHT)

Fox | 981-20-400-R
SKU: FOX-981-20-400-R
Regular price $1,249.95 USD
Regular price $1,374.94 USD Sale price $1,249.95 USD
Sale Sold out
Shipping calculated at checkout.

Out of stock

Quantity

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

Fox 981-20-400-R - CLASS 1/2-1600 FRONT FACTORY RACE 2.0 X 10 EXTERNAL BYPASS (4 TUBE) REMOTE SHOCK (RIGHT)

CLASS 1/2-1600 FRONT FACTORY RACE 2.0 X 10 EXTERNAL BYPASS REMOTE SHOCK (RIGHT)

*APPLICATION SPECIFIC - CLASS 1/2-1600*

FOX devotes countless hours of research and development to design race-winning suspension that withstands incredible punishment and provides consistent performance you can rely on. Regardless of whether you are flying high over the desert or struggling to stick to a rock face on an off-camber climb, our shocks will give you the damping performance, suspension control and proper spring rate to get the job done.

  • NEW proprietary Cerakote® protective ceramic coating over zinc plated basecoat
  • 5/8" hard chrome plated 17-4 H900 stainless steel shaft
  • Owner serviceable and rebuildable
  • JM92 MIL-SPEC oil developed specifically for off-road racing
  • Black Anodized CNC Machined Aluminum Components
Label Name: CLASS 1/2-1600, FRONT, 2.0 FRS, (5/8" SHAFT), EXBP, 4T, R/R, 10", RIGHT
Fox Catalog: OFFROAD
Series: Factory Race
Body Diameter (in): 2
Body Material: Steel
Bottom Mount: Eyelet
Top Mount: Eyelet
Bypass Tubes: 4
Compressed Length (in): 17.13
Extended Length (in): 27.19
Mounting: 1/2 x 1-1/4
Reservoir Dimensions: 2.17 x 8.00
Reservoir Type: Remote
Shaft Size (in): 5/8
Travel (in): 10.06
Type: External Bypass
Eyelet Length (in): 1.68
Valving: 807-24-070
Seal Kit: 803-04-023
Hose: -10 x 31.00
Adjuster Type: External Bypass Clicker - Gen 2
Body Finish: FOX Grey Cerakote
Bypass Tube Size: 1/2
Travel (rounded): 10
