FAST 170032-1 - Connector,Single-Fuel Injector 2 Pin Top Slot Female With Pigtail Harness

FAST 170032-1 - Connector,Single-Fuel Injector 2 Pin Top Slot Female With Pigtail Harness

FAST | 170032-1
SKU: FAST-170032-1
$25.99 USD
$28.59 USD $25.99 USD
Sale Sold out
Shipping calculated at checkout.

Low stock: 2 left

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

FAST 170032-1 - Connector,Single-Fuel Injector 2 Pin Top Slot Female With Pigtail Harness

Denso Fuel Injector Adapter Harness

This fuel injector adapter harness adapts the FAST 32107 242 Lb/Hr LS3 Fuel Injector to a non-Denso fuel injector harness. Kit includes one pre-assembled adapter with pigtail. Requires user to terminate pigtail to injector harness.

Available 2-pin top slot connectors ensure worry-free installation. Part #170032 contains pre-assembled connector and pigtail harness. Single.

  • Pre-Assembled Connector with Pigtail HarnessSingle
Recommended Harnness-Side Minitimer/EV1 Connector: 170599-1
Wire Seal Gauge Range: 20-16
Terminal Size: 2.3
Terminal Gender: Female
Terminal Gauge Range: 22-16
Recommended Wire Gauge: 18
Recommended Harness-Side USCAR/EV6 Connector: 170600-1
Compatible FAST Fuel Injectors: 32107 - Precision-Flow LS3/LS7 Profile 242 lb/hr High?Impedance Fuel Injectors
Pre-Terminated Harness-Side?: No
Number of Pins: 2
Number of Connector Kits: 1
Includes Wires/Pigtails: Yes
Includes Terminal: Yes
Includes Connector Seals: Yes
Connector Type: Denso
Wire/Pigail Length: 5
C.A.R.B. Exempt?: No
C.A.R.B. EO Number: N/A
