Edelbrock 60435 - Cylinder Head BBC Performer RPM Oval Port 100cc Complete Single w/ Springs

Edelbrock 60435 - Cylinder Head BBC Performer RPM Oval Port 100cc Complete Single w/ Springs

Edelbrock | 60435
SKU: EDEL-60435
Regular price $1,436.99 USD
Regular price $1,580.69 USD Sale price $1,436.99 USD
Sale Sold out
Shipping calculated at checkout.

9 in stock

Quantity

Edelbrock 60435 - Cylinder Head BBC Performer RPM Oval Port 100cc Complete Single w/ Springs

Cylinder Head - Performer RPM High-Compression - Assembled - 2.190 / 1.880 in Valves - 290 cc Intake - 100 cc Chamber - 1.550 in Springs - Angle Plug - Aluminum - Big Block Chevy - Each

The Edelbrock #60435 Performer RPM High-Compression O-Port cylinder heads are designed for BB Chevy engines. The #60435 Performer RPM heads are perfect for street performance, daily drivers and muscle cars where more performance is needed

The Edelbrock #60435 Performer RPM High-Compression O-Port cylinder head is designed for Big-Block Chevy applications. The Edelbrock #60435 Performer RPM head is perfect for street performance, daily drivers, street rods and muscle cars where seat-of-the-pants performance is needed. This cylinder head delivers great throttle response and power from 1500 to 6500 rpm. They also feature the highest quality intake and exhaust valves and valve springs. For use on pre-pollution controlled vehicles only.

  • Complete 50-State Street Legal Alum Cylinder Head
  • Out-of-the-Box Bolt-On Performance
  • Design That Improves Intake Port Alignment
  • Outstanding High Performance Street Head
  • Provides A Semi-Open Combustion Chamber
  • 9.2:1 Compression with Flat Top Pistons
  • 8.8:1 Compression With 1987 And Up TBI Dished Pistons
  • Match with Edelbrock Multi-Point EFI to Maximize
Family: Performer RPM
Construction Type: Complete
Exhaust Valve Diameter: 1.88
RGL: WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Intake Valve Diameter: 2.19
EGR Port: No
Exhaust Port Location: Standard
Series: Performer RPM
Valve Spring Diameter: 1.55
Seat Angle: Exhaust 45 deg/Intake 45
Quantity: Sold Individually
Seat Material: Ductile Iron
Retainer Included: Yes
Valve Angle: 26
Exhaust Runner Volume: 110
Camshaft Type: Hydraulic Roller
Deck Thickness: 0.5625
Valve Spring Maximum Lift: 0.700
Guide Material: Manganese Bronze
Horsepower: 500-600
Push Rod Diameter: (Suggested) 0.4375
Rocker Arm Stud Diameter: 0.4375
Valve Stem Diameter: 0.3438
CNC Ported: No
Mounting Hardware Included: No
Valve Springs Included: Yes
Valve Spring Retainers Included: Yes
Valve Seals Included: Yes
Valve Locks Included: Yes
Valve Lock Material: Chromoly Steel
Valve Cover Gasket Included: No
Rocker Arms Included: No
Rocker Arm Studs/Bolts Included: Yes
Material: Aluminum
Assembled: Yes
Intake Runner Volume: 290
Head Casting Number: 6045F
Guide Plates Included: Yes
Guide Plate Material: Chromoly Steel
Grade Type: Performance
Deck Height: 10.2
Cylinder Head Gasket Included: No
Combustion Chamber Volume: 100
Valves Included: Yes
Valve Lock Material: Steel
Guide Plate Material: Hardened Steel
