Edelbrock - 29087
Intake Manifold - Victor JR. LS1 - Square Bore - Single Plane - Cathedral Port - Aluminum - Natural - GM LS-Series - Each
Edelbrock Victor Jr. LS1 Carbureted Intake Manifold Only For Chevrolet LS Gen III
Edelbrock part #29087 Victor Jr. LS1 intake manifold is a high-rise single-plane intake capable of supporting up to 600 hp. The Victor Jr. LS1 features a flange that accepts a square-bore carburetors. It can be used on LS2 applications when matched with MSD's #6012 LS2 ignition controller (available through MSD Performance). Includes a throttle bracket designed to work with 700R-4, 200R-4 and Turbo 350 transmissions. Most applications will require hood modification.
- Converts LS1 Engine to Square Bore Carburetor
- Power Increase From 100-500+ HP
- Use OEM Factory O-Rings for Intake Gasket
Single Or Dual Plane Type: Single
Series: Victor
Vehicle Model: Chevrolet
CNC Ported: No
Gasket Or Seal Included: No
RGL: WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Rear Maximum Height: 4.950
EGR Port: No
Basic Operating RPM Range: 3500-7500
Front Maximum Height: 4.950
Material: Aluminum
Finish: Satin
Center Maximum Height: 4.950
Flange Type: 4150
Grade Type: Performance
