Eagle CRS6100M3DL19-1 - Chevy LS 7/16in 4340 Forged Steel H-Beam Connecting Rods w/ ARP 2000 - Single

Eagle CRS6100M3DL19-1 - Chevy LS 7/16in 4340 Forged Steel H-Beam Connecting Rods w/ ARP 2000 - Single

Eagle | CRS6100M3DL19-1
SKU: CFQW-CRS6100M3DL19-1
$133.99 USD
$147.39 USD $133.99 USD
Sale Sold out
Shipping calculated at checkout.

Out of stock

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

Eagle CRS6100M3DL19-1 - Chevy LS 7/16in 4340 Forged Steel H-Beam Connecting Rods w/ ARP 2000 - Single

SINGLE Rod H-BEAM LS STOCK PIN

Forged 4340 Steel H-Beam Rod - CHEVROLET LS, .945" PIN, ARP L19 BOLTS.

Forged 4340 steel H-Beam connecting rods are forged from a two-piece forging and feature a fully machined and shot-peened surface. Sizing is held to exact tolerances. Specify weight required when ordering. Recommended for competition use.

Big End Width: 0.94 in
Bolts: 7/16 in ARP L19
Bushed for full-floating piston pin: Yes
Center to Center Length: 6.1 in.
Housing Bore: 2.225 in
Length Center Bore To Center Bore: 6.1
Material: Forged 4340 Steel
Pin End Width: 1.06 in
Pin Size: 0.945 in
Rod Journal: 2.1 in.
