Eagle CRS6100L3DL19 - Chevrolet LS .927in Pin ARP L19 Bolts Forged 4340 Steel H-Beam Rods - Set of 8

Eagle CRS6100L3DL19 - Chevrolet LS .927in Pin ARP L19 Bolts Forged 4340 Steel H-Beam Rods - Set of 8

Eagle | CRS6100L3DL19
SKU: CFQW-CRS6100L3DL19
Regular price $743.99 USD
Regular price $826.99 USD Sale price $743.99 USD
Sale Sold out
Shipping calculated at checkout.

Out of stock

Quantity

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

Eagle CRS6100L3DL19 - Chevrolet LS .927in Pin ARP L19 Bolts Forged 4340 Steel H-Beam Rods - Set of 8

H-BEAM LS .927 PIN

Forged 4340 Steel H-Beam Rods - CHEVROLET LS, .927" PIN, ARP L19 BOLTS.

Forged 4340 steel H-Beam connecting rods are forged from a two-piece forging and feature a fully machined and shot-peened surface. Sizing is held to exact tolerances. Sold as a weight-matched set. Equipped with ARP L19 bolts for the ultimate in power-handling capability. Recommended for competition use.

Big End Width: 0.94 in
Bolts: 7/16 in ARP L19
Bushed for full-floating piston pin: Yes
Center to Center Length: 6.1 in.
Housing Bore: 2.225 in
Length Center Bore To Center Bore: 6.1
Material: Forged 4340 Steel
Pin End Width: 1.06 in
Pin Size: 0.927 in
Rod Journal: 2.1 in.
