Eagle - 439340506125
4340 CRANK CHRY LM HEMI 58T RELUCTOR
Forged 4340 Steel Crank - Chrysler MODERN HEMI, 4.050" Stroke, 2.000" Rod JournalS, 58 TOOTH RELUCTOR.
Eagle forged 4340 steel Cranks feature a non-twist forging, .125" fillet radiuses for superior strength so chamfered / narrowed bearings required, nitrided surface and micropolished. Intended for the most demanding applications. Includes 58 tooth reluctor.
Balance Type: Internal
Crankshaft Stroke: 4.050 in
Engine Stroke: 4.05
Flywheel Bolt Count: 8
Flywheel Register Diameter: call
Intended Balance: internal
Main Journal: 2.559 in
Material: Forged 4340 Steel
Minimum Rod Length: 6.125 in
Pilot Bore Diameter: call
Rear Seal Diameter: call
Rod Journal Diameter: 2
Rod Journal Width: 1.900 in
Rod Journal: 2 in
Snout Diameter: call
Target Bobweight: 1780g
