COMP Cams 35-564-44 - Camshaft FW Ford 305Qio8
COMP Cams 35-564-44 - Camshaft FW Ford 305Qio8
SKU: COMP-35-564-44
Regular price
$719.99 USD
Regular price
$791.99 USD
Sale price
$719.99 USD
Shipping calculated at checkout.
Low stock: 1 left
Quantity
DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.
Couldn't load pickup availability
COMP Cams 35-564-44 - Camshaft FW Ford 305Qio8
4-Pattern 253/263 IB, 255/265 OB Hydraulic Roller Cam for Ford 351W
Recommended in larger c.i. and high compression applications. 3500+ Stall.
Hydraulic Roller: 4-Pattern 305QIO8 - Recommended for larger c.i.d. and high compression applications. 3500+ Stall.
Inboard Exhaust Valve Lift: 0.622
Outboard Exhaust Valve Lift: 0.622
Lifters Included: No
Valve Springs Required: Yes
Assembly Lubricant Included: No
Camshaft Gear Attachment: 1-Bolt
Camshaft Material: Billet Steel
Engine Family: Ford 351W 8 Cylinder (1969-1996)
Lifter Type: Hydraulic Roller
Amazon ASIN: B00CWZVA96
C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for On-Road Vehicles?: No
C.A.R.B. Exemption Reason: N/A
C.A.R.B. E.O. Number: N/A
Grind Number: 305QIO8
Camshaft Series: 4-Pattern
Usage: Street/Strip
Cam Type: Hydraulic Roller
Grind Number: 305QIO8
Basic Operating RPM Range: 3300-7,500
Inboard Intake Duration at .050 Inch Lift: 253
Outboard Intake Duration at .050 Inch Lift: 255
Inboard Exhaust Duration at .050 inch Lift: 263
Outboard Exhaust Duration at .050 inch Lift: 265
Advertised Outboard Intake Duration: 307
Advertised Inboard Exhaust Duration: 317
Advertised Outboard Exhaust Duration: 319
Inboard Intake Valve Lift: 0.638
Outboard Intake Valve Lift: 0.638
