COMP Cams 224-302-13 - Stage 2 LST Engine Camshaft - LT1 Camaro/Corvette w/ AFM Delete
COMP Cams 224-302-13 - Stage 2 LST Engine Camshaft - LT1 Camaro/Corvette w/ AFM Delete
SKU: COMP-224-302-13
Regular price
$637.99 USD
Regular price
$701.79 USD
Sale price
$637.99 USD
Shipping calculated at checkout.
27 in stock
Quantity
DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.
Couldn't load pickup availability
COMP Cams 224-302-13 - Stage 2 LST Engine Camshaft - LT1 Camaro/Corvette w/ AFM Delete
Stage 2 LST Cam for LT1 Camaro and Corvette w/ AFM Delete
Maximum HP in LT1 with 4000-7400 RPM powerband. Includes higher volume DI Lobe (+38%). 7500 RPM stability with CK & MK Kits. AFM delete & VVT limiter.
Stage 2 LST 235/248 Hydraulic Roller Cam
Amazon ASIN: B07MKLG39W
C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
Grind Number: 290LMH20
C.A.R.B. E.O. Number: N/A
C.A.R.B. Exemption Reason: N/A
C.A.R.B. Exempt for On-Road Vehicles?: No
Camshaft Series: Low Shock Technology
Usage: Street/Strip
Cam Type: Hydraulic Roller
Grind Number: 290LMH20
Basic Operating RPM Range: 2,700-7,400
Intake Duration at .050 Inch Lift: 235
Exhaust Duration at .050 inch Lift: 248
Advertised Intake Duration: 290
Advertised Exhaust Duration: 297
Lobe Separation: 120
Intake Valve Lift: 0.65
Exhaust Valve Lift: 0.643
Lifters Included: No
Valve Springs Required: Yes
Assembly Lubricant Included: No
Camshaft Gear Attachment: 1-Bolt
Camshaft Material: Billet Steel
Lifter Type: Hydraulic Roller
Engine Family: GM GEN V LT w/ VVT w/o AFM 2014-Present
CK-Kit Upgrade: CK224-302-13
Direct Injection Fuel Pump Lobe Output: 38% More than Stock
Stage: 2
MK-Kit Upgrade: MK224-302-13
Recommended Cam Install Kit for Camaro: 5624
Recommended Cam Install Kit for Corvette: 5626
