COMP Cams 12-364-4 - Camshaft CS 252XFI H-13

COMP Cams 12-364-4 - Camshaft CS 252XFI H-13

COMP Cams | 12-364-4
SKU: COMP-12-364-4
Regular price $316.99 USD
Regular price $348.69 USD Sale price $316.99 USD
Sale Sold out
Shipping calculated at checkout.

Low stock: 2 left

Quantity

COMP Cams 12-364-4 - Camshaft CS 252XFI H-13

Camshaft - Xtreme Fuel Injection - Hydraulic Flat Tappet - Lift 0.477 / 0.472 in - Duration 252 / 266 - 113 LSA - 1300 / 5300 RPM - Small Block Chevy - Each

Fits '58-'02 262-400 c.i.d. Chevy Small Blocks

  • Excellent throttle body injection Cam - Superb for crossfire or carbureted engines - Lots of torque
  • The Xtreme Energy XFIâ„¢ Cam Lobe Series is designed for use with modern induction systems, heads, springs and Rockers. The XFIâ„¢ intake lobes have more lift than the base Xtreme Series, and the XFIâ„¢ exhaust lobes have more area under the curve, for better exhaust flow, than the base exhaust Series. These are the first hydraulic flat tappet profiles designed for use with COMP Cams Beehiveâ„¢ Valve Springs, such as the #26915, #26918 and #26120. The combination of these profiles, the Beehiveâ„¢ Springs, and our Ultra Pro Magnumâ„¢ Rocker Arms in higher ratios, makes for the most revolutionary improvement in hydraulic flat tappet design to date by bringing the latest Race winning Technology to the street.
  • 1: Cams for '55-'57 engines can be custom ordered. 2: The '87+ Chevy Small Block received provisions for Roller lifters. Most '87 - '93 GM cars came with Roller lifters, but most '87 - '95 trucks came with flat tappet lifters in Roller lifter style blocks. If a Roller Cam is desired and your block has OEM-style Roller Cam provisions. COMP Hydraulic Roller Lifter Install Kit for '87-'90 Blocks or '91-'02 Blocks can be purchased, as well as a '87+ OE-Style Hydraulic Roller Cam.
    Camshaft Series: XFI
    Usage: Street/Performance
    Cam Type: Hydraulic Flat Tappet
    Grind Number: 252XFI H13
    Basic Operating RPM Range: 1,300-5,300
    Intake Duration at .050 Inch Lift: 208
    Exhaust Duration at .050 inch Lift: 217
    Advertised Intake Duration: 252
    Advertised Exhaust Duration: 266
    Lobe Separation: 113
    Intake Valve Lift: 0.477
    Exhaust Valve Lift: 0.472
    Lifters Included: No
    Valve Springs Required: Yes
    Assembly Lubricant Included: Yes
    Camshaft Gear Attachment: 3-Bolt
    Camshaft Material: Cast Iron
    K-Kit Upgrade: K12-364-4
    Engine Family: Chevrolet 262-400 c.i. 8 Cylinder (1958-1998)
    Cam and Lifter Kit Upgrade: CL12-364-4
    Lifter Type: Hydraulic Flat Tappet
    SK-Kit Upgrade: SK12-364-4
    Amazon ASIN: B000P5G5T0
    C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
    C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
    C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
    C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
    C.A.R.B. Exempt for On-Road Vehicles?: No
    C.A.R.B. Exemption Reason: N/A
    C.A.R.B. E.O. Number: N/A
    Grind Number: 252XFI H13
