COMP Cams 12-250-20 - Nitrided Camshaft CS XE284H-1
COMP Cams 12-250-20 - Nitrided Camshaft CS XE284H-1
SKU: COMP-12-250-20
Regular price
$468.95 USD
Regular price
$515.84 USD
Sale price
$468.95 USD
Shipping calculated at checkout.
Low stock: 2 left
Quantity
DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.
Couldn't load pickup availability
COMP Cams 12-250-20 - Nitrided Camshaft CS XE284H-1
Xtreme Energy NIT 240/246 Hydraulic Flat Cam for Chevrolet Small Block
Street/strip, 2800+ stall, likes headers and gears, rough idle .Nitrided.
Xtreme Energy NIT 240/246 Hydraulic Flat Tappet Cam for Chevy Small Block (Nitrided) street/strip Applications.
Assembly Lubricant Included: Yes
Camshaft Gear Attachment: 3-Bolt
Camshaft Material: Nitrided Cast Iron
Engine Family: Chevrolet 262-400 c.i. 8 Cylinder (1958-1998)
Lifter Type: Hydraulic Flat Tappet
Amazon ASIN: B002EE4CHW
C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for On-Road Vehicles?: No
C.A.R.B. Exemption Reason: N/A
C.A.R.B. E.O. Number: N/A
Grind Number: XE284H
Camshaft Series: Xtreme Energy
Usage: Street/Strip
Cam Type: Hydraulic Flat Tappet
Grind Number: XE284H
Basic Operating RPM Range: 2,300-6,500
Intake Duration at .050 Inch Lift: 240
Exhaust Duration at .050 inch Lift: 246
Advertised Intake Duration: 284
Advertised Exhaust Duration: 296
Lobe Separation: 110
Intake Valve Lift: 0.507
Exhaust Valve Lift: 0.51
Lifters Included: No
Valve Springs Required: Yes
