Bilstein AK1053 - Shock Absorbers

Bilstein AK1053 - Shock Absorbers

Bilstein | AK1053
SKU: BIL-AK1053
Regular price $108.97 USD
Regular price $119.87 USD Sale price $108.97 USD
Sale Sold out
Shipping calculated at checkout.

14 in stock

Quantity

Bilstein AK1053 - Shock Absorbers

Shock - AK Series - Monotube - 9.21 in Compressed / 14.11 in Extended - Linear - Steel - Yellow Paint - Front - GM F-Body 1971-81 - Each

46mm Monotube Shock Absorber

Bilstein AK Series shock absorbers are designed for motorsports applications that require the use of the OE mounting components. Each shock absorber features a monotube design with steel spring valve discs for consistent, fade free performance and superior durability. AK Series shock absorbers are ideal for racers who demand reliable performance that also meets their sanctioning body's mounting requirements.

  • Monotube design ensures consistent, fade-free performance in all conditions
  • Direct fit (OE) mounting design
  • Race-winning valvings for optimum weight transfer, feel, and grip in various track conditions
Segment: Motorsports
Extended Length (IN): 14.11
Spring Seat Included: No
Collapsed Length (IN): 9.21
Adjustable Damping: Non-Adjustable
Extended Length (MM): 358.5
Internal Design: Monotube
Upper Mount Type: Stem
Stroke/Travel Length (IN): 4.90
Body Design: Stock Mount Smooth Body
PartType: Shocks / Struts
Series: AK Series
Body Material: Steel
Stroke/Travel Length (mm): 124.5
Rebound @0.26m/s: 2515
Rebound @0.52m/s: 4275
Collapsed Length (MM): 234.0
Compression @0.26m/s: 730
Boot Included: No
Compression @0.52m/s: 1200
Finish: Yellow Paint
Shaft Diameter: 11mm
Piston Diameter: 46mm
Lower Mount Type: Bar Pin
Piston Type: Linear
