Bilstein 25-331875 - B8 5165 8.8in Travel Remote Reservoir - Eye/Eye 170/60

Bilstein 25-331875 - B8 5165 8.8in Travel Remote Reservoir - Eye/Eye 170/60

Bilstein | 25-331875
SKU: BIL-25-331875
Regular price $259.00 USD
Regular price $284.90 USD Sale price $259.00 USD
Sale Sold out
Shipping calculated at checkout.

142 in stock

Quantity

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

Bilstein 25-331875 - B8 5165 8.8in Travel Remote Reservoir - Eye/Eye 170/60

B8 5165 - Suspension Shock Absorber

46mm Monotube Shock Absorber

Bilstein B8 5165 remote reservoir shock absorbers are designed to be used on custom off-road vehicles in order to achieve the desired ride of your light truck or SUV. These high gas pressure monotube shock absorbers are sold by various lengths and valve rates to accommodate a wide range of uses and custom applications. All B8 5165 shock absorbers come equipped with 5/8 inch eyelets with hour glass bushings on both ends. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting, providing a clean, low profile installation. B8 5165 remote reservoir shock absorbers will increase overall durability of your custom vehicle allowing you to conquer the harshest of off-road environments.

  • 46mm monotube design ensures consistent, fade-free performance in all conditions
  • Self-adjusting deflective disc valving reacts immediately to surface changes enabling maximum vehicle control
  • Remote reservoir increases shock oil capacity for greater heat dissipation
Internal Design: Monotube
Collapsed Length (MM): 346.5
Finish: Zinc Plated
Compression @0.52m/s: 595
Series: B8 5165
Adjustable Damping: Non-Adjustable
Lower Mount Type: Eye 5/8in
Upper Mount Type: Eye 5/8in
Body Design: Smooth Body (Non-Coilover)
Mount Type: Eye-to-Eye
Shaft Diameter: 14mm
Collapsed Length (IN): 13.64
Optional Reservoir Clamp: 11-176015
Extended Length (IN): 22.43
Rebound @0.52m/s: 1810
PartType: Shocks / Struts
Stroke/Travel Length (IN): 8.79
Extended Length (MM): 569.7
Boot Included: No
Segment: Light Truck
Stroke/Travel Length (mm): 223.3
Reservoir: Yes
Piston Diameter: 46mm
Spring Seat Included: No
