Bilstein 24-336888 - 2014 Ford F-150 RWD Only B8 5100 (Ride Height Adjustable) Front Shock - 0-2.1in Lift

Bilstein 24-336888 - 2014 Ford F-150 RWD Only B8 5100 (Ride Height Adjustable) Front Shock - 0-2.1in Lift

Bilstein | 24-336888
SKU: BIL-24-336888
Regular price $176.00 USD
Regular price $245.85 USD Sale price $176.00 USD
Sale Sold out
Shipping calculated at checkout.

Out of stock

Quantity

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

Bilstein 24-336888 - 2014 Ford F-150 RWD Only B8 5100 (Ride Height Adjustable) Front Shock - 0-2.1in Lift

B8 5100 (Ride Height Adjustable) - Suspension Shock Absorber

46mm Monotube Shock Absorber

Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting.  Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.

  • 46mm monotube design ensures consistent, fade-free performance in all conditions
  • Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology
  • Adjustable spring seat offers 0-2.75in of lift, depending on the application
Collapsed Length (IN): 16.05
Finish: Zinc Plated
Series: B8 5100 (Ride Height Adjustable)
Adjustable Damping: Non-Adjustable
PartType: Shocks / Struts
Lower Mount Type: Crossbar
Stroke/Travel Length (mm): 134.4
Body Design: Snap Ring Grooved Body (Coilover)
Piston Diameter: 46mm
Segment: Light Truck
Spring Seat Included: Yes
Extended Length (mm): 542.1
Extended Length (IN): 21.34
Stroke/Travel Length (IN): 5.29
Upper Mount Type: Stem
Reservoir: No
Boot Included: No
Collapsed Length (mm): 407.6
Shaft Diameter: 18mm
Internal Design: Monotube
