Bilstein 24-336871 - 2014 Ford F-150 B8 5100 Series Front 46mm Monotube Shock Absorber

Bilstein 24-336871 - 2014 Ford F-150 B8 5100 Series Front 46mm Monotube Shock Absorber

Bilstein | 24-336871
SKU: BIL-24-336871
Regular price $176.00 USD
Regular price $245.85 USD Sale price $176.00 USD
Sale Sold out
Shipping calculated at checkout.

Out of stock

Quantity

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

Bilstein 24-336871 - 2014 Ford F-150 B8 5100 Series Front 46mm Monotube Shock Absorber

B8 5100 (Ride Height Adjustable) - Suspension Shock Absorber

46mm Monotube Shock Absorber

Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting.  Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.

  • 46mm monotube design ensures consistent, fade-free performance in all conditions
  • Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology
  • Adjustable spring seat offers 0-2.75in of lift, depending on the application
Collapsed Length (MM): 429.6
Series: B8 5100 (Ride Height Adjustable)
Adjustable Damping: Non-Adjustable
PartType: Shocks / Struts
Lower Mount Type: Crossbar
Upper Mount Type: Stem
Stroke/Travel Length (mm): 139.7
Extended Length (MM): 569.1
Boot Included: No
Piston Diameter: 46mm
Collapsed Length (IN): 16.91
Body Design: Snap Ring Grooved Body (Coilover)
Shaft Diameter: 18mm
Segment: Light Truck
Spring Seat Included: Yes
Internal Design: Monotube
Reservoir: No
Stroke/Travel Length (IN): 5.50
Extended Length (IN): 22.41
Finish: Zinc Plated
