Bilstein

Bilstein 24-296946 - Shock Absorbers

MSRP: $197.06
$179.15
( saved $17.91 )
Write a Review
  • Bilstein 24-296946 - Shock Absorbers
  • PLEASE NOTE: Pictures are repsentative of style, may be generic.
Adding to cart… The item has been added
SKU:
BIL-24-296946
UPC:
651860847733
  • Free Ground Shipping

  • No Restocking Fee

  • Safe Payments

  • No Backorders Ever

Bilstein - 24-296946

Shock - SMX Series - Monotube - C5-R5 Valve - Steel - Black Paint - Rear - GM A-Body / F-Body / G-Body - Each

46mm Monotube Shock Absorber

Bilstein SMX Series shock absorbers are specifically designed for motorsports applications that mandate the use of stock mount (OE) suspension components. Designed using 46mm monotube technology, the shocks are available in a variety of damping options including dry kit designed specifically to provide the best options for a variety of race track types and conditions. Built in the USA with precision components and top quality controls, the SMX Series shocks deliver Bilstein’s famous fade-free performance and consistency in a factory-mount package that championship winning racers demand.

  • Stock mount design for GM metric chassis applications
  • 46mm piston design for maximum damping control
  • 46mm piston design for maximum damping control

Body Material: Steel
Extended Length (IN): 21.02
Piston Type: Linear
Spring Seat Included: No
Rebound @ 10"/sec: 275
PartType: Shocks / Struts
Body Diameter (ID): 46mm
Collapsed Length (MM): 329.0
Extended Length (MM): 534.0
Spring Hardware: N/A
Body Design: Stock Mount Smooth Body
Collapsed Length (IN): 12.95
Lower Mount Type: Eye
Series: SMX Series
Upper Mount Type: Bar Pin
Internal Design: Monotube
Segment: Motorsports
Boot Included: No
Finish: Black Paint
Compression @ 10"/sec: 275
Adjustable Damping: Non-Adjustable
