Bilstein - 24-253222
B8 5100 (Ride Height Adjustable) - Suspension Shock Absorber
46mm Monotube Shock Absorber
Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-2.75 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology
- Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology
Collapsed Length (MM): 407.6
Reservoir: No
Body Design: Snap Ring Grooved Body (Coilover)
Lower Mount Type: Crossbar
Extended Length (MM): 543.5
Finish: Zinc Plated
Extended Length (IN): 21.40
Segment: Light Truck
Series: B8 5100 (Ride Height Adjustable)
Boot Included: No
Body Diameter (ID): 46mm
Spring Seat Included: No
Collapsed Length (IN): 16.05
Upper Mount Type: Stem
Adjustable Damping: Non-Adjustable
Internal Design: Monotube
PartType: Shocks / Struts
