Bedslide 15-6347-CG - 5 5 FT Super Short Bed Tundra Suburban And Tahoe 75 Percent Ext 1500lbs Contractor 63X47 Inch

Bedslide 15-6347-CG - 5 5 FT Super Short Bed Tundra Suburban And Tahoe 75 Percent Ext 1500lbs Contractor 63X47 Inch

The BedSLIDE for 5 5 FT Super Short Bed Toyota Tundra Chevy Suburban And Tahoe 75 Percent Ext 1500lbs Contractor 63X47 Inch. ALL BedSLIDES ARE MADE TO ORDER FROM THE MANUFACTURER. PLEASE ALLOW A MINIMUM OF TWO WEEK TURN TIME .
BedSLIDES Are Manufactured WithA 1/4 Inch Dimension Tolerance. 48 Inch Widths Are 48.25 Inch and fit a standard sheet of plywood. BedLINERS/BedRUGS May Alter Fitment. Please Check Dimensions to ensure proper application.
Call for Custom Size Applications.
BedSLIDE 1500 Contractor Features

• 1500lbs Capacity (evenly distributed)
• 75 Percent Extension
• Guardrails and headboard to contain your cargo
• WEATHERDECK our exclusive composite light weight decking is durable in all elements
• 32 inch Wide Grab Bar for easy access from either side
• Multiple Locking Positions for safety and convenience
• BedTRAX with D Ring Tie Downs for cargo management
• Heavy duty CAM Follower Bearings and hard latch system
• Lifetime Warranty Available with registration. 5 year standard

Product Details

• HEIGHT: 4 1/2 inches from truck Bed to deck.
• Bearings: (2) 3282lb static rated Cam Follower Bearings on load bearing end with (4) ball sealed roller Bearings for guides.
• Locking: Locking positions every 10-12 inches with locks closed and fully opened.
• Installation: 1 hour. It FTs recommended to have a dealer install. Install over Bedliners is not recommended as adjustments may need to be made and Bedliners vary. For aluminum Beds use part HALUMKT. Improper Installation can lead to corrosion.
