Aeromotive 18398 - Fuel Pump - Universal - Phantom 200 - 60psi - 6-10in Depth

Aeromotive 18398 - Fuel Pump - Universal - Phantom 200 - 60psi - 6-10in Depth

Aeromotive | 18398
SKU: AFS-18398
$585.99 USD
$613.21 USD $585.99 USD
Sale Sold out
Shipping calculated at checkout.

Low stock: 1 left

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

Aeromotive 18398 - Fuel Pump - Universal - Phantom 200 - 60psi - 6-10in Depth

EFI Returnless Phantom 200, 58-60 PSI Internally Regulated. ORB-06 Outlet and Vent Ports. Requires AN-06 Supply Line and High Flow Filter.

Aeromotive Inc. is a true high performance aftermarket manufacturer specializing in fuel delivery and fuel delivery components. Utilizing aerospace tolerances and procedures, three generations of track experience, and a meticulous approach to engineering, Aeromotive Fuel Systems has become the absolute pinnacle of performance fuel delivery.

EFI HP on Gas: 250 FI
EFI HP on Gas: 400 NA
EmissionFullDES: 3 - This Product is ILLEGAL for Street or Off Highway use and is only intended for Closed Course Competition use, Except for 1965 and older US Manufactured, California Certified vehicles; 1967and older US Manufactured, Federal Certified vehicles, or 1967 and older Foreign Manufactured vehicles , which may have this product installed as long as the vehicle still meets emissions standards for the year of the vehicle and retains any original or retrofit emissions control devices, including EGR, A.I.R and any NOx device required for the year of the vehicle.
Filter Included: No
Fuel Delivery Type: Fuel Injection
Fuel Sending Unit Included: No
Fuel Type: Gas
Gasket Or Seal Included: Yes
Grade Type: Performance
Integrated Controller: No
Internal Or External: Internnal
Maximum Current Draw: 8.3
Maximum Flow Rating: 200
Maximum Pressure: 55-60
Mounting Bracket Included: Yes
Mounting Hardware Included: Yes
Negative Ground: Yes
Outlet Outside Diameter: AN-06
Outlet Type: Female Thread
Pulse Width Modulation Compatible: Yes
Pump Design: turbine impeller
Regulator Included: No
Seal And Lock Ring Included: Yes
Series: Phantom
Strainer Included: Yes
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Threaded Stud
Universal Or Specific Fit: Universal
Voltage: 12
Wiring Harness Included: No
