Aeromotive - 13114
Fuel Pressure Regulator - A1000 Marine - 40 to 75 psi - In-Line - 10 AN Female O-Ring Inlet - 10 AN Female O-Ring Outlet - 6 AN Female O-Ring Return - 1/8 in NPT Port - Fittings Included - E85 / Gas / Diesel - Each
Marine EFI Regulator.
A true performance EFI Regulator designed for medium to high horsepower marine applications. Features Aeromotive?s high-flow design, superb pressure control and legendary durability. This pressure control regulator has logged more hours than any other performance EFI marine regulator in the world! Base pressure adjustable from 40-75 PSI. Fuel pressure rises on a 1:1 ratio with boost. 1/8' gauge port included. Provides (2) ORB-10 inlet ports and one ORB-06 return port.
Adjustable: Yes
Color: Black
Fuel Delivery Type: Fuel Injection
Gauge Included: No
Gauge Port: Yes
Grade Type: Performance
Inlet Gender: Female
Inlet Gender.1: Female
Inlet Port Diameter: ORB-10
Marine Approved: Yes
Maximum Pressure: 75
Minimum Pressure: 40
Mounting Bracket Included: Yes
Outlet Port Diameter: ORB-10
Port Quantity: 2
Pressure Range: 40-75
Return Port Diameter: ORB-06
Return Port Gender: Female
Vacuum/Boost Port: Yes
