Aeromotive - 11108
Fuel Pump - A1000 Marine - Electric - In-Line / In-Tank - 600 lb/hr at 45 psi - 10 AN Female O-Ring Inlet / Outlet - Black - E85 / Gas - Each
Marine 1000HP Fuel Pump.
Certified to ISO 8846, SAE J1171 United States Coast Guard Requirements for Ignition Protection Fire Resistance. Carbureted Engines: up to 1500 HP naturally aspirated and up to 1200 HP forced air induction. Fuel Injected Engines: up to 1300 HP naturally aspirated and up to 1000 HP forced air induction.
- Carbureted Engines: up to 1500 HP – naturally aspirated up to 1200 HP – forced air induction
- Fuel Injected Engines: up to 1300 HP – naturally aspirated up to 1000 HP – forced air induction
Carb HP on E85: 1050
Carb HP on Gas: 1500
EFI HP on E85: 910
EFI HP on Gas: 1300
Filter Included: No
Fuel Delivery Type: Carburation & Fuel Injection
Fuel Sending Unit Included: No
Fuel Type: Gas/E85
Gasket Or Seal Included: No
Grade Type: Performance
Inlet Outside Diameter: ORB - 10
Inlet Type: Female Thread
Integrated Controller: No
Internal Or External: External Or Internal
Maximum Current Draw: 18 @ 45 psi
Maximum Flow Rating: 1000
Maximum Pressure: 100
Motor Style: Brushed
Mounting Bracket Included: Yes
Mounting Hardware Included: No
Negative Ground: Yes
Outlet Outside Diameter: ORB - 10
Outlet Type: Female Thread
Pulse Width Modulation Compatible: Yes
Pump Design: Rotary Vane
Regulator Included: No
Seal And Lock Ring Included: No
Series: A1000
Strainer Included: No
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Threaded Stud
Universal Or Specific Fit: Universal
Voltage: 12
Wire Quantity: 0
Wiring Harness Included: No
